Structural & Miscellaneous Steel detailing
The detailing team at Art Iron Engineering has a diverse background in the detailing of structural and miscellaneous steel.
Our team is familiar with common fabrication & specification such as AISC, OSHA, ASTM, SJI, SDI etc.
The detailing process is fully automated and we use the latest version of software of SDS2, Tekla to achieve –
- Building Information Modelling
- 3D Modelling
- Shop Drawings
- Erection Plans & Sections
- Anchor Bolt Drawings
- Embed Plans
- Lintel Plans
- Beam Detail
- Column Detail
- Stair
- Handrail
- Truss
- Purlin
- Connection Sketches
- CNC (.DXF) Files for Fabrication
- Shop Bolt List
- Field Bolt List
- Material Summary
- Project Tracking
- Advance Bill of Material
